Product presentation
Amorphous is a new type of soft magnetic alloy material, which uses the advanced super-cooling technology to directly cool molten metal at a rate of millions of degrees per second, forming an amorphous thin ribbon with a thickness of 25-35μm, and obtaining an amorphous alloy structure with short range order and long range disorder on the atomic arrangement combination, which is completely different from traditional metals and alloy materials in terms of microstructure. Therefore, it has unparalleled excellent characteristics of traditional metal materials in physical properties, chemical properties, mechanical properties and many other aspects. In addition, the preparation process is completely different from the traditional metallurgical process, made of liquid steel one step into amorphous thin ribbon, saving the traditional metallurgical process in casting, forging, intermediate annealing, rolling and other processes, saving a lot of energy, and no pollutant emissions, amorphous alloy is known as environmental protection, energy saving, efficient new green materials.
Fe-based amorphous ribbon, with its high permeability, high saturation magnetic induction, low iron loss and excellent stability, meet the needs of today's electronic products of high frequency, high current, miniaturization, energy saving direction of development, it can replace silicone, permalloy and ferrite, widely used in power, electronic products
technological process
Application area
Inverter reactor,transformer core
Wide constant permeability magnetic inductance core,pfc inductance core
Intermediate frequency transformer core,Distribution transformer core
Amorphous electromagnetic shielding foils for digital electronics
